650-100 Lever Clamp
  • 150kg clamping force – widened rail minimises bending under load
  • Induction‑hardened rail – delivers superior strength and long‑term durability
  • 120° rotatable movable chuck – securely holds irregularly shaped workpieces
  • Quick‑convert design – easily switches from clamp to spreader
  • Ratchet design – enables fast, effortless high‑force application
  • Engineering‑grade plastic body – lightweight yet strong for reliable use
  • Elegant appearance with premium surface finish – combines functionality with refined aesthetics
Product Overview

650-100mm Lever Clamp delivers a stable clamping force of up to 150kg with an 100mm throat depth, making it ideal for securing irregularly shaped workpieces in woodworking and industrial applications. The induction‑hardened rail provides superior strength and wear resistance, while the widened rail design effectively reduces bending under high loads.

The movable chuck can be rotated 120° to firmly hold contoured or non‑flat surfaces, offering exceptional flexibility for complex clamping tasks. A ratchet design enables easy and rapid achievement of high clamping force with minimal effort, and the clamp can be quickly converted to a spreader for added versatility. Constructed from strong engineering‑grade plastic for lightweight durability, the clamp offers a clamping capacity from 150mm to 800mm.

An optimised quick‑release trigger ensures fast, effortless disengagement, enhancing workflow efficiency. Engineered for reliable performance and adaptability, the 650-100mm is built to handle demanding clamping challenges with ease.

Specifications
Art. No. Throat Depth (mm) Clamp Force (kg) Clamp Range (mm) Spread Range (mm) L x W x H (mm) Wt. (kg) Pcs. / Ctn. Ctn. Dim. (cm)
DT65010150 100 150 150   290 x 130 x 30 0.51 12 31 x 22 x 15
DT65010200 100 150 200   340 x 130 x 30 0.54 12 36 x 22 x 15
DT65010250 100 150 250   390 x 130 x 30 0.59 12 40 x 23 x 15
DT65010300 100 150 300   440 x 130 x 30 0.64 12 46 x 23 x 15
DT65010400 100 150 400   540 x 130 x 30 0.74 12 55 x 23 x 15
DT65010500 100 150 500   640 x 130 x 30 0.84 12 66 x 22 x 15
DT65010600 100 150 600   740 x 130 x 30 0.94 12 76 x 23 x 15
DT65010800 100 150 800   940 x 130 x 30 1.14 12 94 x 23 x 15
