650-80 Lever Clamp
  • 120kg clamping force – widened rail minimises bending under load
  • Induction‑hardened rail – delivers superior strength and long‑term durability
  • 120° rotatable movable chuck – securely holds irregularly shaped workpieces
  • Quick‑convert design – easily switches from clamp to spreader
  • Ratchet design – enables fast, effortless high‑force application
  • Engineering‑grade plastic body – lightweight yet strong for reliable use
  • Elegant appearance with premium surface finish – combines functionality with refined aesthetics
Product Overview

650-80mm Lever Clamp delivers a stable clamping force of up to 120kg with an 80mm throat depth, making it ideal for securing irregularly shaped workpieces in woodworking and industrial applications. The induction‑hardened rail provides superior strength and wear resistance, while the widened rail design effectively reduces bending under high loads.

The movable chuck can be rotated 120° to firmly hold contoured or non‑flat surfaces, offering exceptional flexibility for complex clamping tasks. A ratchet design enables easy and rapid achievement of high clamping force with minimal effort, and the clamp can be quickly converted to a spreader for added versatility. Constructed from strong engineering‑grade plastic for lightweight durability, the clamp offers a clamping capacity from 100mm to 300mm.

An optimised quick‑release trigger ensures fast, effortless disengagement, enhancing workflow efficiency. Engineered for reliable performance and adaptability, the 650-80mm is built to handle demanding clamping challenges with ease.

Specifications
Art. No. Throat Depth (mm) Clamp Force (kg) Clamp Range (mm) Spread Range (mm) L x W x H (mm) Wt. (kg) Pcs. / Ctn. Ctn. Dim. (cm)
DT65080100 80 120 100   235 x 121 x 31 0.38 12 26 x 22 x 15
DT65080160 80 120 160   295 x 121 x 31 0.41 12 32 x 22 x 15
DT65080200 80 120 200   335 x 121 x 31 0.44 12 36 x 22 x 15
DT65080250 80 120 250   385 x 121 x 31 0.48 12 41 x 22 x 15
DT65080300 80 120 300   440 x 121 x 31 0.53 12 45 x 22 x 15
