699 Heavy Duty Parallel Clamp
  • Heat‑treated, serrated steel rail – delivers high clamping force with minimal deflection
  • Heavy zinc plating – passes 72‑hour salt spray test for outstanding corrosion resistance
  • Soft cushions + deep throat – protect workpieces and provide a larger clamping area
  • Ergonomic handle – enables quick, easy force application with reduced user effort
  • Anti‑slip system – 6‑side hobbing and built‑in steel plate; positioning arm locks securely anywhere along the bar
  • Premium Duratec finish – modern aesthetics with superior surface quality and durability
Product Overview

699 Heavy Duty Parallel Clamp (95mm depth) delivers reliable, up to 600 kg force clamping for woodworking and industrial applications. Featuring a hardened rail with hexagonal serration and an advanced zinc plating that withstands 72‑hour salt spray testing, this clamp offers superior corrosion resistance and non‑slip performance even under heavy loads.

The ductile cast arms with a unique positioning design allow secure locking at any point along the 300mm–1500mm bar, providing flexible capacity for a wide range of workpiece sizes.

Built‑in steel plates on the rail further enhance durability and slip resistance, while replaceable soft cushions protect the workpiece surface from marring or damage.

The ergonomically designed handle ensures comfortable grip and reduced user fatigue during extended use. Combining robust construction, anti‑corrosion protection, and thoughtful detail, it is engineered for long‑lasting accuracy and dependable performance in the toughest workshop environments.

Specifications
Art. No. Throat Depth (mm) Clamp Force (kg) Clamp Range (mm) Spread Range (mm) L x W x H (mm) Wt. (kg) Pcs. / Ctn. Ctn. Dim. (cm)
DT69995300 95 600 300 480 525 x 149 x 50 2.41 4 58 x 19 x 21
DT69995400 95 600 400 580 625 x 149 x 50 2.59 4 68 x 19 x 21
DT69995500 95 600 500 680 725 x 149 x 50 2.76 4 78 x 19 x 21
DT69995600 95 600 600 780 825 x 149 x 50 2.93 4 88 x 19 x 21
DT69995800 95 600 800 980 1025 x 149 x 50 3.26 4 108 x 19 x 21
DT69995100 95 600 1000 1180 1225 x 149 x 50 3.63 4 128 x 19 x 21
DT69995120 95 600 1200 1380 1425 x 149 x 50 3.97 4 148 x 19 x 21
DT69995150 95 600 1500 1680 1725 x 149 x 50 4.43 4 178 x 19 x 21
