856-65mm Bar Clamp
  • 70kg clamping force – I‑beam + widened rail minimises bending under load
  • Long‑leverage handle – enables easy application of high pressure
  • Optimised quick‑release trigger – ensures fast, effortless disengagement
  • Quick‑convert design – easily switches from clamp to spreader
  • Soft protective cushions – safeguard workpieces from damage
  • Engineering‑grade plastic body – lightweight yet strong for reliable use
  • Elegant appearance with premium surface finish – combines functionality with refined aesthetics
Product Overview

856-65mm Medium Duty Bar Clamp delivers a stable clamping force of up to 70kg with a 65mm throat depth, making it an ideal choice for light to medium woodworking, DIY projects, and general workshop applications. The induction‑hardened rail provides improved strength and wear resistance, while the widened rail design effectively reduces bending under load.

A long‑leverage handle allows easy application of pressure, and the clamp can be quickly converted to a spreader for added versatility. Soft protective cushions safeguard workpieces from damage, and the strong engineering‑grade plastic body ensures lightweight durability. With a clamping capacity ranging from 150mm to 600mm, this clamp offers flexibility for smaller to medium project sizes.

A quick‑release trigger ensures fast, effortless disengagement, enhancing workflow efficiency. Engineered for dependable performance and ease of use, the 856-60mm is a practical and reliable companion for everyday tasks.

.
Specifications
Art. No. Throat Depth (mm) Clamp Force (kg) Clamp Range (mm) Spread Range (mm) L x W x H (mm) Wt. (kg) Pcs. / Ctn. Ctn. Dim. (cm)
DT85665150 65 70 150 305 321 x 180 x 38 0.37 12 35 x 25 x 20
DT85665300 65 70 300 460 476 x 180 x 38 0.45 12 51 x 24 x 20
DT85665450 65 70 450 610 631 x 180 x 38 0.53 12 65 x 24 x 20
DT85665600 65 70 600 765 781 x 180 x 38 0.61 12 81 x 25 x 19
