858-65mm Medium Duty Bar Clamp
  • 70kg clamping force – widened rail minimises bending under load
  • Induction‑hardened rail – delivers improved strength and long‑term durability
  • Long‑leverage handle for easy pressure application; optimised quick‑release trigger for effortless disengagement
  • Quick‑convert design – easily switches from clamp to spreader
  • Soft protective cushions – safeguard workpieces from damage
  • Engineering‑grade plastic body – lightweight yet strong for reliable use
  • Premium surface finish and texture – combines functionality with refined quality
Product Overview

858-65mm Medium Duty Bar Clamp delivers a stable clamping force of up to 70kg with a 65mm throat depth, making it an ideal choice for light to medium woodworking, DIY projects, and general workshop applications. The induction‑hardened rail provides improved strength and wear resistance, while the widened rail design effectively reduces bending under load.

A long‑leverage handle allows easy application of pressure, and the clamp can be quickly converted to a spreader for added versatility. Soft protective cushions safeguard workpieces from damage, and the strong engineering‑grade plastic body ensures lightweight durability. With a clamping capacity ranging from 150mm to 600mm, this clamp offers flexibility for smaller to medium project sizes.

A quick‑release trigger ensures fast, effortless disengagement, enhancing workflow efficiency. Engineered for dependable performance and ease of use, the 858-65mm is a practical and reliable companion for everyday tasks.

Specifications
Art. No. Throat Depth (mm) Clamp Force (kg) Clamp Range (mm) Spread Range (mm) L x W x H (mm) Wt. (kg) Pcs. / Ctn. Ctn. Dim. (cm)
DT85865150 65 70 150 335 320 x 180 x 30 0.34 12 35 x 25 x 21
DT85865300 65 70 300 485 470 x 180 x 30 0.415 12 51 x 25 x 21
DT85865450 65 70 450 640 620 x 180 x 30 0.49 12 82 x 24 x 20
DT85865600 65 70 600 795 780 x 180 x 30 0.58 12 87 x 24 x 20
